Thermal analysis is a critical testing method used in metal casting processes to measure the temperature, cooling curve, and solidification behavior of molten metal, enabling the prediction and control of casting quality in advance. This analysis identifies phase transformations, crystallization processes, and potential defects within the molten metal during casting, preventing errors that could occur on the production line. Proper thermal analysis application provides higher casting quality, lower scrap rates, and excellence in process control, making it one of the indispensable quality control tools of modern foundries.

One of the most important factors determining quality in the metal casting industry is the behavior of molten metal during solidification. This process directly affects all characteristics of the final product, from microstructural formation to mechanical properties, from porosity to crack formation. Thermal analysis offers foundry engineers a powerful tool to understand and manage this critical process. Each inflection point on the cooling curve of molten metal tells an important story in the world of metallurgy: parameters such as liquidus temperature, eutectic reactions, peritectic transformations, and solidus temperature provide valuable information about the chemical composition, purity, and casting suitability of the melt.

One of the biggest challenges in casting processes is ensuring that molten metal maintains consistent quality every time. Each ladle from the furnace can show different properties due to raw material variations, melting conditions, and atmospheric interactions. Thermal analysis detects these variations instantly, allowing corrective measures to be taken before casting. For example, in ductile iron production, even a 5°C deviation in liquidus temperature can cause serious deterioration in graphite morphology, and this can only be detected through proper thermal analysis.

One of the greatest advantages of thermal analysis is that results are obtained almost instantly. The molten metal is taken from the ladle, poured into a thermal analysis cup, and within 2-3 minutes the cooling curve is completed and analysis results are obtained. This speed gives foundry engineers the opportunity to make decisions while the molten metal is still hot and manageable. If the analysis results deviate from expected values, the melt composition can be adjusted, the inoculation process can be repeated, or if necessary, the melt can be reprocessed instead of being sent for casting. This approach minimizes scrap rates while maximizing production efficiency.

In traditional foundries, quality control was typically performed through destructive or non-destructive testing after casting and cooling of the part. When defects were detected using this method, the entire casting batch had already been completed and scrapped. Thermal analysis radically changes this approach by moving quality control to the very beginning of the process, before the molten metal is poured into the mold. This approach adopts the philosophy of "predict and control in advance" rather than "test and fix," forming the foundation of modern manufacturing understanding.

Furthermore, data obtained through thermal analysis is valuable not only for instant decisions but also for long-term process improvement studies. Each recorded cooling curve can be stored in a database to analyze trends over time. Answers to questions such as which furnace charges yield more stable results, which raw material batches perform better, and how seasonal changes affect melt quality emerge through proper analysis of this data. This allows foundries to optimize their processes within a continuous improvement cycle and maintain their competitive advantage.

Another important aspect of thermal analysis is cost savings. Every defective part prevented through proper analysis directly translates into cost advantage. Additionally, knowing melt quality in advance allows for more precise adjustment of casting parameters (such as filling speed, pressure, temperature). This provides significant savings in energy consumption and labor costs. Research shows that foundries using thermal analysis experience a 25-40% reduction in scrap rates and achieve 10-15% savings in total production costs.

Today, with digitalization and Industry 4.0 applications, thermal analysis systems have become integrated with next-generation technologies. Modern thermal analysis devices can automatically transmit measurement results to the facility's central control system, generate instant alerts, and even predict potential future deviations using AI-powered algorithms. This allows foundries to minimize human error while strengthening data-driven decision-making processes.

In conclusion, the answer to the question "What does thermal analysis do?" is quite clear: It guarantees casting quality before parts are produced, ensures process stability, reduces costs, and forms the foundation of sustainable production. Supported by the right analysis equipment and thermal analysis cups, this method plays a leading role in the quality control strategies of modern foundries.

What Is Thermal Analysis and Why Is It Important?

Thermal analysis is performed by recording the temperature change of molten metal over a specific period and interpreting this data. This method, used in casting processes, is indispensable for understanding the metal's behavior during solidification. As molten metal cools, it undergoes phase transformations at specific temperatures, and these changes directly affect the final mechanical properties of the cast part.

Through thermal analysis, foundry engineers can instantly monitor the following critical parameters of molten metal:

• Liquidus temperature: The point at which the metal is completely melted
• Solidification start temperature: The moment crystallization begins
• Solidus temperature: The point at which the metal becomes completely solid
• Under-cooling degree: Cases where crystallization is delayed
• Eutectic and peritectic reactions: Phase transformations of alloying elements

These data are the most important factors determining casting quality. For example, in ductile iron production, accurate determination of liquidus temperature is critical for achieving spheroidal graphite formation. In aluminum castings, a narrow solidification range results in a denser and more porosity-free structure.

What Are the Purposes of Thermal Analysis?

Thermal analysis is used for various purposes at different stages of the casting process:

1. Carbon Equivalent (CE) Determination

In cast iron production, accurate determination of carbon and silicon ratios is vital for final product quality. Thermal analysis calculates the carbon equivalent through liquidus temperature, checking whether the molten metal has the correct composition.

2. Evaluation of Liquid Metal Quality

Gases, oxides, and other impurities in molten metal affect solidification behavior. Thermal analysis detects these effects, allowing necessary interventions.

3. Control of Alloying Elements

The ratios of alloying elements cause characteristic changes in the solidification curve. These changes are analyzed to check whether the melt meets the target alloy composition.

4. Ensuring Process Stability

In mass production, every casting must meet the same quality standard. Thermal analysis ensures process stability by providing the same cooling behavior for each melt.

5. Reducing Scrap Rates

By detecting solidification defects before casting occurs, defective melts are prevented from being sent for casting. This provides a significant reduction in scrap rates.

How Is Thermal Analysis Performed?

Thermal analysis is carried out through a fairly simple but precise procedure:

1. Sample Collection: A specific amount of metal sample is taken from the molten metal ladle.
2. Pouring into Thermal Analysis Cup: The collected metal sample is poured into a specially designed thermal analysis cup.
3. Temperature Measurement: Temperature values during cooling are recorded second by second using a sensitive thermocouple (temperature sensor) placed inside the cup.
4. Cooling Curve Plotting: The recorded temperature data is plotted as a graph against time. This graph is called a "cooling curve."
5. Data Analysis: Critical points on the cooling curve (liquidus, solidification start, eutectic temperature, etc.) are identified and interpreted.
6. Decision Making: Based on the analysis results, a decision is made on whether the molten metal is suitable for casting. Composition adjustments are made if necessary.

Thermal Analysis Cups and Their Importance

One of the most critical pieces of equipment in the thermal analysis process is the thermal analysis cup. These cups are designed to safely contain the molten metal sample while optimizing heat transfer. A quality thermal analysis cup should have the following features:

• High temperature resistance: Withstanding molten metal up to 1600°C
• Homogeneous heat distribution: Even heat transfer for accurate cooling curves
• Chemical resistance: Material structure that does not react with molten metal
• Disposable or reusable options: Suitable solutions according to production volume

Thermal analysis cups must have standard dimensions and material properties to obtain accurate and repeatable results. Cup options are available specifically designed for different metal types (cast iron, steel, aluminum, copper-based alloys).

Sustainable Production with Thermal Analysis

Sustainability is becoming increasingly important in the casting industry. Thermal analysis helps reduce environmental footprint by providing less scrap, lower energy consumption, and more efficient use of raw materials. Preventing defective melts from being cast prevents energy waste and ensures more efficient use of natural resources.

Additionally, optimizing processes through thermal analysis allows more sound parts to be produced with the same amount of energy. This means gains both economically and environmentally.

Frequently Asked Questions (FAQ)

Question: Which metals can thermal analysis be applied to?

Answer: Thermal analysis can be applied to cast iron (gray, ductile, malleable), steel, aluminum and its alloys, copper-based alloys, and many other casting metals. Different analysis parameters and cup types are available for each metal type.

Question: How long does it take to get thermal analysis results?

Answer: The analysis process typically takes 2-3 minutes from sample collection to results. This allows intervention while the molten metal is still hot.

Question: What does a thermal analysis cup do?

Answer: A thermal analysis cup safely contains the molten metal sample and ensures accurate temperature sensor measurement. The cup's material and design directly affect measurement accuracy.

Question: What defects can be detected with thermal analysis?

Answer: Many process defects can be detected with thermal analysis, including incorrect carbon/silicon ratio, excessive gas content, insufficient inoculation, incorrect alloy ratios, and solidification defects.

Question: Is thermal analysis equipment expensive?

Answer: Thermal analysis equipment is available at different price ranges according to foundry needs. However, considering the scrap reduction and quality improvement it provides, the return on investment period is quite short.

Reliable Thermal Analysis Solutions with Altınkum Döküm

Choosing the right thermal analysis equipment and thermal analysis cups is of great importance to increase quality and efficiency in your casting processes. As Altınkum Döküm, we are with you with our extensive thermal analysis product range suitable for different metal types and production processes. We offer quality and technically supported solutions for all your needs, from high-precision thermal analysis cups to reliable measurement devices.

For more detailed information about thermal analysis and thermal analysis cups, to review our products, or to select the most suitable analysis solution for your production process, please contact our expert team.
